Journal of Health and Medical Sciences

ISSN 2622-7258

Published: 14 July 2020

3D Vector Reconstruction of the Atlas from Anatomical Sections of Korean Visible Human at the Laboratory of Clinical and Digital Anatomy of Paris Descartes University

Kante A, Daou M, Coulibali B, Uhl. Jf, Delmas V, Chevallier JM, Ba B, Ongoiba N

Paris 5 University (France), University of Sciences, Techniques and Technologies of Bamako (Mali)

pdf download

Download Full-Text Pdf

10.31014/aior.1994.03.03.121

Pages: 260-269

Keywords: 3D Vector Modelling, Atlas, Digital Anatomy, Korean Visible Human

Abstract

Aim: Carry out a 3D vector reconstruction of the atlas from the anatomical sections of the "Korean Visible Human" for educational purposes. Material and methods: The anatomical subject was a 33-year-old Korean man who died of leukemia. It measured 164 cm and weighed 55 kg. This man donated his body to science. Her body was frozen and cut into several anatomical sections after an MRI and CT scan. These anatomical sections were made using a special saw called a 0.2 mm thick cryomacrotome. Thus 8,100 cuts were obtained. Only the sections numbered 780 to 860 were used for our study. A segmentation by manual contouring of the different parts of the atlas was done using the software Winsurf version 3.5 on a laptop PC running Windows 7 equipped with a Ram of 8 gigas. Results: Our 3D vector model of the atlas is easy to manipulate using the Acrobat 3DPDF interface. The atlas accessible in a menu can be displayed, hidden or made transparent, and 3D labels are available as well as educational menus for learning anatomy. Conclusion: This original work constitutes a remarkable educational tool for the anatomical study of the atlas and can also be used as a 3D atlas for simulation purposes for training in therapeutic gestures.

References

  1. Ackerman M. J. The Visible Human project. A resource for education. Acad Med.1990;74(6):667-70.

  2. Cho Z. H. 7.0 Tesla MRI Brain Atlas, In Vivo Atlas with Cryomacrotome Correlation. Springer, New York.2009

  3. Cho Z. H; Calamate F; Chi JG. 7.0 Tesla MRI brain white matter atlas. Panmun, Seoul.2012

  4. Chung BS ; Shin DS ; Brown P ; Choi J ; Chung MS. Virtual dissection table including the Visible Korean images, complemented by free software of the same data. Int J Morphol. 2015 ;33(2):440-45

  5. Dai JX ; Chung MS ; Qu RM ; Yuan L ; Liu SW ; Shin DS. The Visible Human Projects in Korea and China with improved images and diverses applications. Surg.Radiol.Anat. 2012 ;34(6):527-34.

  6. Kim CH ; Choi SH ; Jeong JH ; Lee C ; Chung MS ; HDRK-Man. A whole-body voxel model based on high-resolution color slice images of a Korean adult male cadaver. Phys Med Biol.2008;53(15):4093-106.

  7. Park HS ; Chung MS ; Shin DS ; Jung YW ; Park JS. Accessible and informative sectioned images, color-coded images, and surface models of the ear. Anat Rec.2013;296(8):1180-86.

  8. Park JS ; Chung MS ; Hwang SB ; Lee YS ; Har DH ; Park HS. Visible Korean Human:Improved serially sectioned images of the entire body. IEEE Trans.Med.Imaging. 2005;24(3):352-60.

  9. Park JS ; Chung MS ; Hwang SB ; Lee YS ; Har DH ; Park HS. Technical report on semiautomatic segmentation by using the Adobe Photoshop.J Digit Imaging.2005;18(4):333 -43.

  10. Park JS ; Chung MS ; Hwang SB ; Shin BS ; Park HS. Visible Korean Human : Its techniques and applications.Clin Anat. 2006;19(3):216-24.

  11. Park JS ; Chung MS ; Shin DS ; Har DH ; Cho Z.H ; Kim YB ; Han JY ; Chi J.G. Sectioned images of the cadaver head including the brain and correspondences with ultrahigh field 7.0 T MRIs.Proc IEEE.2009;97(12):1988-96.

  12. Quackenbush D ; Ratiu P ; Kerr,J. Segmentation of the Visible Human Data Sets.The Visible Human Project Conference Proceedings. October 1996:7-8.

  13. SchiemannT ; Freudenberg J ; Pflesser B ; Pommert A ; Priesmeyer K ; Riemer M ; Schubert R ; Tiede U ; Höhne KH. Exploring the Visible Human using the VOXEL-MAN framework. Comput Med Imaging Graph.2000;24(3):127-32.
